  • DRAMINSKI iScan - veterinary Ultrasound (DRM)

Do you really think that using ultrasound scanners in the field is not comfortable? We designed DRAMINSKI iScan to disprove this myth! We will deliver a high quality image in a small and light device and you will make a correct diagnosis and advise a proper treatment.

Type Of ULTRASOUND Black and white, Portable
Cena po zalogowaniu
Cena po zalogowaniu
Shipping within 1-30 working days
Leave your phone

Ultra light, ultra mobile, ultrasound scanner iScan.


  The iScan DRAMINSKI is an absolutely revolutionized ultrasound scanner to be used in the field! It was created thanks to miniaturization of the electronic systems and the use of efficient power supply. When designing the project and implementing the suggested solutions we consulted with veterinary doctors in order to create the DRAMINSKI iScan the most adjusted to your needs and situations which take place in the field. portable ultrasound scanner with goggles, light goggles, comfortable ultrasound glasses, ultrasound goggles, LCD goggle

Efficient work in every conditions with DRAMIŃSKI Goggle System

This time our newest model of ultrasound video goggles is more comfortable, with excellent adjustment on the user’s head. If you examine a lot of animals in a row or work in very light rooms, these goggles with clear, legible image will make your work more comfortable.

Comfort and high standard of work is guaranteed by:

five-point system of adjustment: the head circumference, depth, height, angle of inclination and setting of the distance between the goggles and the eyes, removable cover of the forehead part of the goggles (easy to clean), colourful display, resolution 640x480, excellent, clear image, excellent visibility of the surroundings during your work (safety of work).

DRAMINSKI goggles – the most comfortable goggles on the market.

DRAMINSKI goggles operate with DRAMINSKI 4Vet mini, DRAMINSKI iScan 2 and DRAMINSKI iScan ultrasound scanners.

Why is it worth having the DRAMINSKI iScan?

You will quickly understand positive qualities of this ultrasound scanner created to be used in the field because: image

YOU CAN TAKE IT EVERYWHERE

It is ultra light. The weight of a complete ready to work device is just 2 kg. It is ultra small. Its dimensions are 17 x 17 x 6 cm. Thanks to this you do not need assistance of another person to carry out the tests. image

YOU CAN WORK WITH IT ALL THE TIME

Having a spare battery which takes 2 h to be charged and which works 5 hours, it is enough after 5-hour continuous work to have a 5-second break. This is what you need to exchange the battery. image

YOU CAN MAKE PROFESSIONAL DIAGNOSTICS
in the range of:

complete reproduction of cows and mares, as well as other species, e.g. fish, sinew and eye balls of horses, pathological states of mammary gland, objective estimation of milk cows’ conditions, other tests with the use of ultrasound devices. image

EVEN IN DIRECT SUNLIGHT YOU WILL SEE AN EXCELLENT IMAGE

We used fully digital imaging (B, B+B, B+M) in LCD backlit screen. Thanks to the sun protective shield you will be able to see a clear image on the screen even in the direct sunlight. image

YOU CAN WASH IT IN RUNNING WATER

The dirty device is not a problem! You can easily wash you DRAMINSKI iScan in running water. image

YOU CAN TRANSMIT THE DATA TO YOUR COMPUTER

Use USB 2.0 to transmit the images and cine loops to your computer. image

DO NOT WORRY ABOUT ITS DURABILITY

Alumin body of the scanner guarantees its extreme durability. Moreover, the iScan has a solid case which is easy to wash as it is made of high quality plastic. It also protects the scanner against the influence of high and low temperatures. image

IN THE CASE OF MALFUCTION, YOUR COMFORT IS OUR PRIORITY

We know how reliable our ultrasound scanners are. That is why we give a 2-year warranty. Thanks to the benefits mentioned above, the DRAMINSKI iScan gathers a lot of positive opinions all over the world. It is set as an example of a diagnostic device ideal to be used in very demanding conditions. (check the vets’ opinions)

The set includes:

scanner’s body with electronic linear probe, carrying strap, which allows hanging the device on the neck, package of external batteries (1 item in a standard version, 2 items in prestige version), battery charger, power cable for the charger, USB cable for data transmission, sunscreen (in prestige version), a bottle of ultrasound gel (in prestige version), abridged manual, manual and a programme for data transmission to a PC, recorded on a CD, Transport case.

Warranty: 24 months

  vetfartuch700px

SPECIAL OFFER !

Now when you buy one of the ultrasound scanners (iScanANIMALprofi 2 or 4Vet mini) you will receive a protective apron with DRAMINSKI logo as a gift! It has appropriate length, comfortable tie and practical color to provide comfort of work during examinations in the field. Offer is valid until stocks run out!

Technical data

Dimensions 17.0 x 17.0 x 6.0 cm
Unit weight 1720 g including probe
Battery weight 280 g
Image presentation (projection) mode B Mode – live imaging,
B+B Mode (2B Mode – Dual Mode Display),
B+M Mode
Probe frequency and type electronic linear 7.5 MHz (from 4 to 9MHz)
Scanning range from 0 to 12 cm (for linear probe, rectal use)
Screen LCD, LED screen, 5.0’’ diagonal
Keyboard membrane
Cine loop (image sequence) 256 frames (ca. 20 seconds)
Image memory 200 images with date, index No. and description
Cine loop memory 50 cine loops with date, index No. and description
Transmission to the computer through the USB2.0 port
Power source Li-ion battery pack, 14.4 V, 3.1Ah
Continuous operation on fully charged battery about 5 h
Pack charging time 2 hrs 30 min
Battery low indicator automatic – graphic indicator
Working temperature – 10°C do + 40°C
Storage temperature 0°C do + 45°C
